DBA4650 – 4000 Series HD Brake Rotor; Front
Subaru
BRZ (ZC6) Coupe 2012 - 2020
- 2.0 2012 - 2020
Forester (SG) Suv 2002 - 2008
- 2.0 Turbo (AWD) (SG5) 2002 - 2003 Awd
- 2.0 Turbo (AWD) (SG5) 2003 - 2008 Awd
- 2.5 (AWD) 2003 - 2004 Awd
- 2.5 (AWD) 2004 - 2008 Awd
- 2.5 Turbo (AWD) 2004 - 2008 Awd
Forester (SH) Suv 2008 - 2013
- 2.0 TD (AWD) 2008 - 2013 Awd
Forester (SJ) Suv 2012 - 2019
- 2.0 2012 - 2019
- 2.0 TD 2012 - 2018
Impreza (GC / Version 5) Sedan 1992 - 2000
- GT 2.0 Turbo (GC8) (218HP / 160KW) 1998 - 1999
Impreza (GD / A) Sedan 2000 - 2007
- WRX 2.0 Turbo (218HP / 160KW) 2000 - 2002
Impreza (GD / B - E) Sedan 2001 - 2007
- WRX 2.0 Turbo (225HP / 165KW) 2002 - 2005
Impreza (GD / F - G) Sedan 2001 - 2007
- WRX 2.5 Turbo (230HP / 169KW) 2005 - 2007
Impreza (GH) Hatchback 2007 - 2012
- 2.0 TD 2009 - 2011
- 2.0 TD 2011 - 2012
- WRX 2.5 Turbo (227HP / 169KW) 2007 - 2008
- WRX 2.5 Turbo (265HP / 198KW) 2008 - 2012
Legacy (BE) Sedan 1998 - 2003
- 2.0 Twin Turbo (BE5) (280HP / 191KW) 2000 - 2003
- 2.5 (156HP / 115KW) 1999 - 2003
- 3.0 (209HP / 154KW) 2000 - 2003
Legacy (BG) Estate 1994 - 1999
- 2.0 Twin Turbo (BG5) 1996 - 1999
Legacy (BH) Estate 1998 - 2003
- 2.0 Twin Turbo GT - B (BH5) (260HP / 191KW) 1998 - 2003
- 2.0 Twin Turbo GT - B (BH5) (280HP / 206KW) 1998 - 2003
Legacy (BL) Sedan 2003 - 2009
- 2.0 TD (BLD) (150HP / 110KW) 2006 - 2009
- 2.5 (165HP / 121KW) 2003 - 2007
- 2.5 (173HP / 127KW) 2007 - 2009
Legacy (BM) Sedan 2009 - 2014
- 2.0 TD (BMD) (150HP / 110KW) 2009 - 2014
- 2.5 (167HP / 123KW) 2009 - 2014
Legacy (BP) Estate 2003 - 2009
- 2.0 TD (BPD) (150HP / 110KW) 2006 - 2009
Legacy (BR) Estate 2009 - 2014
- 2.0 TD (BRD) (150HP / 110KW) 2009 - 2014
- 2.5 (167HP / 123KW) 2009 - 2014
Outback (BH) Estate 1999 - 2003
- 2.5 (156HP / 115KW) 1999 - 2003
- 3.0 (209HP / 154KW) 2000 - 2003
Outback (BP) Suv 2003 - 2009
- 2.0 TD (150HP / 110KW) 2008 - 2009
- 2.5 (165HP / 121KW) 2003 - 2005
- 2.5 (173HP / 127KW) 2006 - 2009
- 3.0 (245HP / 180KW) 2003 - 2009
Outback (BR) Suv 2009 - 2014
- 2.0 (150HP / 110KW) 2009 - 2014
- 2.0 TD (150HP / 110KW) 2009 - 2014
- 2.5 (167HP / 123KW) 2009 - 2014
XV (GP) Suv 2012 - 2017
- 1.6 (AWD) 2012 - 2017 Awd
- 2.0 (AWD) 2012 - 2017 Awd
- 2.0 TD (AWD) 2012 - 2017 Awd
Toyota
GT86 (ZN6) Coupe 2012 - 2020
- 2.0 2012 - 2020
GT86 (ZN8) Coupe 2021 - Present
- GR86 2.4 2021 - Present
€174.50 Incl. VAT
- Manufacturer: DBA
- Material: Cast Iron
- Package Contents: 1x Brake Disc
- DBA4650 – 4000 Series HD Brake Rotor; Front DBA 4000 Series HD Brake Rotors are forged from high carbon alloyed iron and subjected to Thermal Stability Profiling, DBA’s metallurgy ensures resilience against the heightened stress and heat generated during intense braking applications, delivering consistent performance and them more suitable for more aggressive driving or high-performance applications than DBA’s Street Series brake rotors.
- Additionally, a large range of DBA’s 4000 Series Brake Rotors feature DBA’s Kangaroo Paw ventilation system, incorporating a series of 144 diamond and teardrop-patterned pillars, that achieve an impressive 30% increase in surface area and a 20% improvement in cooling efficiency compared to traditional straight vane designs.
- All 4000 Series Brake rotors feature Thermographic heat paint markings that change colour at specific temperature thresholds to assist with the monitoring of braking temperatures and rotor fatigue.
(+31) 85 303 71680 Start Live Chat
DBA
Disc Brakes Australia (DBA) is a leading manufacturer of high-performance brake rotors, founded in Melbourne in 1976. DBA's patented T2 and T3 slot patterns, along with their 4000 and 5000 series rotors, are trusted by motorsport competitors and performance enthusiasts globally. Every DBA rotor is manufactured and tested in Australia to rigorous quality standards.
Talk to a real motorsport specialist.
EU-based, motorsport-experienced. We'll walk through your application before you buy.
Description
DBA4650 – 4000 Series HD Brake Rotor; Front DBA 4000 Series HD Brake Rotors are forged from high carbon alloyed iron and subjected to Thermal Stability Profiling, DBA’s metallurgy ensures resilience against the heightened stress and heat generated during intense braking applications, delivering consistent performance and them more suitable for more aggressive driving or high-performance applications than DBA’s Street Series brake rotors.
Additionally, a large range of DBA’s 4000 Series Brake Rotors feature DBA’s Kangaroo Paw ventilation system, incorporating a series of 144 diamond and teardrop-patterned pillars, that achieve an impressive 30% increase in surface area and a 20% improvement in cooling efficiency compared to traditional straight vane designs.
All 4000 Series Brake rotors feature Thermographic heat paint markings that change colour at specific temperature thresholds to assist with the monitoring of braking temperatures and rotor fatigue. DBA 4000 Series HD Brake Rotors showcase a sleek OE-style rotor finish, catering to drivers seeking the advantages of a 4000 Series rotor while desiring an OE-style appearance, including controlled race divisions.
Additional information
| Manufacturer | DBA |
|---|---|
| Bolt Circle Diameter mm | 100 |
| Bolt Hole Quantity | 00, 5 |
| Disc Diameter (mm) | 295 |
| Disc Finish | Plain (Blank) |
| Disc Height (mm) | 58 |
| Hub Hole Diameter (mm) | 58 |
| Disc Construction | 1-Piece |
| Disc Side | Left/Right |
| Max Thickness | 25 |
| Min Thickness | 23 |
| Disc Type | Vented |
| Disc Quality | Premium |
| Material | Cast Iron |
| Package Contents | 1x Brake Disc |
| Approvals | ECE R90 Approved |
| Approval Number | E11*90R02/06*59762*00 |
| Brake Location | Front |
