Boost Controllers

A boost controller lets a turbo engine run more boost than its wastegate spring alone would allow, by changing the pressure signal the wastegate sees. This section covers manual and in-cabin controllers, dual-stage units, electronic controllers, boost control solenoids and a covered toggle switch.

Without a controller, the wastegate starts to open as soon as boost reaches its spring rating. A controller in the signal line holds back or bleeds off part of that signal, so the gate stays shut longer and boost climbs to a higher, set level. The spring still sets the floor: the controller adds boost above it but cannot bring boost below it. Holding the gate firmly shut until the set point can also bring boost in sooner than a gate that creeps open.

Pick the type by how much control you need:

• Manual controllers: most use a ball-and-spring valve in the signal line, set once under the bonnet. They are simple, but every change means opening the bonnet.
• In-cabin and dual-stage units: a dial inside the car, or two set levels with a switch, for example a lower setting for wet roads. Manual units come in blue, black or gold.
• Electronic controllers: a control unit reads boost and pulses a solenoid to hold a target. They are listed by range, 40 psi or 3 bar, and one comes in a 60 mm body in black or silver.
• Solenoids: a 3-port solenoid works with a single-port gate, while a 4-port solenoid feeds both sides of a twin-port gate for firmer control. Check the coil’s power draw, such as 12.7 W, against the controller.

Plumb the controller between a steady boost source and the wastegate, with short runs of sound hose and secure clamps. A split hose on the gate side removes the opening signal and can send boost far past target, so check those hoses often. Raise boost in small steps while watching a gauge and the air–fuel ratio, because more boost needs fuel, ignition timing and charge cooling to match. On cars whose ECU already controls boost, an add-on controller can fight the factory strategy, so a calibration change is often cleaner.
